3D Printing Inconel

metal 3d printing services

3D Printed Inconel

Inconel 3D Printing

Inconel 3D Printing uses the Selective Laser Melting (SLM) method to create high-performance parts from nickel-chromium superalloys at 3DSPRO. 3D printed Inconel is widely used in the aerospace, energy, and automotive industries to produce heat-resistant and corrosion-resistant components, such as turbine blades, exhaust manifolds, and advanced precision heat exchangers.

Advantages of Inconel Metal 3D Printing

  • High Strength-to-Weight Ratio
  • Excellent Corrosion and Oxidation Resistance
  • Superior Fatigue and Creep Resistance
  • Thermal Stability and High-Temperature Performance
  • Low Thermal Expansion Coefficient
  • Good Weldability

Available Inconel Types

Inconel 718

Inconel 718, also known as UNS N07718 or Alloy 718, is one of the most widely used nickel-chromium superalloys. Maximum printing size is 280*280*350mm.

Key Mechanical Properties
  • Selective Laser Melting

    Technology

  • 300 HV

    Hardness

  • 8.15 g/cm³

    Density

  • 99.5%

    Relative Density

  • 980MPa

    Tensile Strength

  • 13%

    Elongation at Break

  • 700MPa

    Yield Strength

  • 200GPa

    Elastic Modulus

  • 15µm

    Roughness Ra

Recommended Applications
  • Aerospace Turbine Blades and Vanes
  • Rocket Engine Combustion Chambers
  • Gas Turbine Nozzle Guide Vanes
  • Oil & Gas Downhole Drill Bits
  • Conformal-Cooled Heat Exchangers
  • High-Temperature Industrial Tooling
Learn More >>

3D Plus™ Post-processing for Inconel Parts

  • Bead Blasting
  • Bead Blasting
  • Electrocoating
  • Electrocoating
  • Electroplating
  • Electroplating
  • Polishing
  • Polishing
  • Powder Coating
  • Powder Coating
  • Sand Blasting
  • Sand Blasting
  • Spray Painting
  • Spray Painting
  • Tapping
  • Tapping
  • Threading
  • Threading
  • Tumbling
  • Tumbling
Discover 3D Plus™ Solutions
